Ceramic ignition resistance for thermo stoves and pellet boilers
  • Ceramic ignition resistance for thermo stoves and pellet boilers
  • Ceramic ignition resistance for thermo stoves and pellet boilers
  • Ceramic ignition resistance for thermo stoves and pellet boilers

Ceramic ignition resistance for thermo stoves and pellet boilers

Place of Origin China
Brand Name KRHX
Certification CE
Model Number KR-H4
Product Details
Nmae:
CERAMIC IGNITION RESISTANCE
Max Working Temperature:
600-1100℃
Feature:
Sustainable
Voltage:
220V/230V
Power:
180W,250W,200W 280W,300W
Application:
Pellet Stove
Dimension(L*W*H):
φ11.5*106mm
Flange:
Ceramic Flange
Cable:
φ0.8/1mm
Connector:
Customized
Highlight:

Ceramic Ignition Resistance

Payment & Shipping Terms
Minimum Order Quantity
10
Packaging Details
In cartons each containing 20 boxes
Delivery Time
5-8 workdays
Payment Terms
L/C, D/A, D/P, T/T, Western Union
Supply Ability
1000PCS/Week
Product Description

Ceramic ignition resistance for thermo stoves and pellet boilers



CERAMIC IGNITION RESISTANCE



Ceramic ignition resistance for thermo stoves and pellet boilers 0



Introducing the Kairui ceramic biomass igniter range, an advance in ignition technology for solid wood fuels. Ceramic Igniter for pellet stoves, designed to ignite wood pellets and wood chips in stoves, boilers and burners. Tested for more than 10,000 ON/OFF cycles, with rapid ignition times.



Specification

KR Series Specification Dimension Max. Dia. Flange Max Temperature
KR-H4 220V
200-300W
11.5 x 93 mm 17.5 mm 1020 Deg.C
KR-H4 220V
260-300W
11.5 x 106 mm 17.5 mm 1020 Deg.C
KR-H4 220V
300-350W
11.5 x 115 mm 17.5 mm 1020 Deg.C



Ceramic ignition resistance for thermo stoves and pellet boilers 1

Application

Ceramic igniters suitable for ignition of wood pellet, logs, wood chips, coal for stoves, boilers and burners, includes the following:

•Wood pellet stove

•Wood pellet boiler

•Wood pellet burner

•Wood chips burner

•Straw burner

•Other biomass burner

•Gas Stove Burner ect

Ceramic ignition resistance for thermo stoves and pellet boilers 2

Product-package

All ceramic igniter are packed in cartons lined with EPE, foam, 40 pcs to a box.4 boxes to a carton.

Ceramic ignition resistance for thermo stoves and pellet boilers 3



Company profile

Kairui Corporation specialises in ceramic hot surface igniters and has many years experience of working closely with customers to develop bespoke solutions for innovative appliance manufacturers. Kairui are a trusted manufacturer of hot surface ignition products to many industry sectors.
